Diagnostics page
The Diagnostics page of the Workspace window lists the issues Prism for AL found while loading the workspace or building the Code graph: unresolved modules, files that do not parse, code graph errors and workspace advisories. Each issue has its details, which you can copy for a bug report.
Opening it
The page appears in the rail of the workspace window only while there are issues, with a red mark for errors and an amber one for warnings. Select Diagnostics in the rail, or a count on the Diagnostics expander of the Solution page, which opens the matching tab.
| # | Name | Description |
|---|---|---|
| 1 | Diagnostics | The rail button of this page. It shows only while Prism for AL has found issues. |
| 2 | Overview | The number of issues of each kind; see Overview tab. |
| 3 | Modules | The modules Prism for AL could not resolve; see Modules tab. |
| 4 | Compilation units | The files that do not parse; see Compilation units tab. |
A tab shows only when it has something to list. The CodeGraph tab, after Compilation units, shows when the code graph has translation errors.
Overview tab
The Diagnostics card (“Workspace health issues”) gives a count per kind of issue. Select a count's link to open its tab.
| Row | Meaning |
|---|---|
| Unresolved modules | Dependencies Prism for AL could not find. Opens the Modules tab. |
| Runtime packages message |
“The workspace has unresolved dependencies and one or more runtime packages. …” Prism for AL cannot
read runtime packages, which are encrypted; add the modules as app.json projects or as
packages that are not encrypted. See Packages ignored when opening folder.
|
| Compilation unit errors | Files that do not parse. Opens the Compilation units tab. |
| Graph translation syntax errors | “Internal Prism for AL error while translating code to the graph.” Opens the CodeGraph tab. |
| Graph translation name resolution errors | “Internal Prism for AL error while resolving code names for the graph.” Opens the CodeGraph tab. |
| Nested project advisories | app.json files found inside a workspace folder, which Prism for AL leaves out of the
workspace. Each one is listed with its severity (Error, Warning or
Hint), its path, which you can select to reveal it in File Explorer, and what it
means.
|
| Missing package directories |
An al.packageCachePath setting points to a folder that does not exist, so no packages
were read from it. The dependencies expected there are unresolved, or come from the package cache
when Search Package Cache is on.
|
| Modules not updated by "AL: Download symbols" | Modules that the search depth All loaded as dependencies of dependencies. AL: Download symbols in Visual Studio Code does not download them, so nothing updates them, and they may be outdated. Each module is listed with the reason. |
Modules tab
| # | Name | Description |
|---|---|---|
| 1 | Unresolved modules | The modules no module of the workspace could be resolved to, with Publisher, Name and Version constraint (≥ the lowest version asked for). Select one to see its details. |
| 2 | Core | The module's identity: its id, with a button that copies it to the clipboard and one that shows the module's relations in the module graph (“View module relations for this module.”), its publisher and name, and what to do: “Module not found in workspace”, or “Download symbols from server and reload workspace” when the workspace should have it. |
| 3 | Discovery | The files Prism for AL considered for the module, with Path (select it to show the file), Kind and Error. |
| 4 | Usages | The modules that require this module, with Publisher, Name (select it to go to that module) and the Version constraint each imposes. |
Unresolved modules explains how to fix an unresolved module.
Compilation units tab
| # | Name | Description |
|---|---|---|
| 1 | Path | The file that does not parse. |
| 2 | Message | The error message. |
| 3 | Row (error) | One row per error, grouped by module. Select a row to see its details on the right. |
| 4 | Details | The module, the path, the message, the error, and the source code of the file with the part before the error dimmed. |
| 5 | Copy to clipboard | Copies the details of the error to the clipboard. |
| 6 | Search | Type to filter the errors by their text. |
Parse errors explains what to do about a parse error.
CodeGraph tab
| # | Name | Description |
|---|---|---|
| 1 | Toggle object groups | Expands or collapses every group. |
| 2 | Copy to clipboard | Copies the details of the selected error. |
| 3 | Error | The error of the selected row. |
| 4 | Errors | The objects whose code could not be put into the code graph, grouped by kind of error, by module and by object type. A module group's context menu has Go to Module, which shows the module in the Solution page. |
These errors are faults in Prism for AL, not in your code. Answers from the code graph about the objects listed may be incomplete. Send the details to us, as described below.
Copy an error's details
Open the context menu of a row on the Compilation units or the CodeGraph tab:
To report an error to us:
- Select Copy diagnostic info to clipboard on the error, or the copy button of its details.
- Open the Feedback window and paste the details into your message.
- Send it.
Related
- Unresolved modules: fix a module Prism for AL cannot resolve.
- Parse errors: what to do about a file that does not parse.
- Discovery page: every file Prism for AL considered while loading.
- Code graph page: the state and metrics of the code graph.
